485-0052-240

2x4mm²
894070
Not in stock, on order
Product question

What would you like to know about 485-0052-240?

Send

Description

Miracles keep happening...

But the fact that the new SC-DUAL BLUE is a hit will not surprise anyone who ever had the pleasure of listening to its big brother, the SC-QUADRA BLUE. The SC-DUAL BLUE is not a slimmed down version of the SC-QUADRA BLUE, but a speaker cable with a special pitch which has been optimized for a 2-pole connectivity. This connection is recommended for stereo systems where the speaker terminals are bridged or have no bi-wiring/bi-amping connections. The SC-DUAL BLUE impresses by its smart construction, the timeless and modern design and a straight-in-your-face, impulsive and natural reproduction. This cable brings out the best your hi-fi system has to offer.

Advantages:

  • Tight, low-capacitance stranding of the 2 wires
  • Concentric, ultra compact stranding of the 504 x 0.10 mm single wires
  • Gas-injected insulation with dual interconnection
  • Screen made of tight copper braiding with 95% optical coverage
  • Use of ultra-grade copper quality with conductor smoothing (OFC Class6N, 99.9999%)

Application:

  • High-quality hifi speaker cable for demanding requirements
Properties: Analog, OFC oxygen free copper
Application area: Installation, Studio / Broadcast
Application: Speaker Cable
Colour: blue
Construction: (2LIY4,0mm²)(ST)CY
Construction (audio): (2LIY4,0mm²)CY
Jacket material: S-PVC
Jacket Ø [mm]: 15,50
Jacket Ø ["]: 0.6102
Number of Channels (audio): 1
Inner conductor: 2
Inner conductor (audio): 2
Inner conductor (audio) [mm²]: 4,00
Inner conductor (audio) [sqin]: 0.0062
AWG (audio): 11
Shielding: Copper braiding + AL / PT foil, Copper braiding tin-plated
Copper strands (audio): 504
Copper strand Ø (audio) [mm]: 0,10
Copper strand Ø (audio) ["]: 0.0039
Weight per 1 m [g]: 340
Weight at 1000 ft. [lbs]: 228.7914
Fire load per m [kWh]: 0,55
Style variant: round
Packing: 50m spool, bulk stock
Temperature min. [°C]: -20
Temperature max. [°C]: 70
Width [mm]: 15,5
Width ["]: 0.6102
Height [mm]: 15,5
Height ["]: 0.6102
Capac. cond./cond. per 1 m (audio) [pF]: 65
Capacity wire/wire at 1 ft. (audio) [pF]: 19.812
Insulation resist. per 1 km (audio) [GΩ]: 0,005
Insulation resist. per 1000 feet (audio) [GΩ]: 0.0015
BPVo-Euroclass: Fca
