The hymns of praise by cable...
Advantages:
- Neutral and loss-free audio transmission due to special copper strand design
- 100 % shielding due to dense helical copper mesh screen plus extra AL fleece/AL foil
- Professional technology at a budget price
- Available in a notch- and cold-resistant PUR version
Application:
- Professional studio and microphone technology
- Outdoor transmission/OB van
- Permanent stage application
100m Rulle
Vill ni beställa mindre än 100m tillkommer en klippkostnad på 50:-
Technical Data:
Properties: Analog
Properties: OFC oxygen free copper
Application area: Studio / Broadcast
Application area: Mobile outdoor / indoor
Application area: Stage / live
Application area: Installation
Application area: ELA 100 V
Application: Microphone Cable
Colour: black
Colour detailed: black
Signal transmission: symmetrical
Jacket material: PVC
Jacket Ø: 6,5 mm
Number of Channels (audio): 1
Inner conductor (audio): 2
Inner conductor (audio): 0,25 mm²
Inner conductor Ø (audio): 0,56 mm
AWG (audio): 23
Shielding: copper spiral sleeve tin-plated 95 % + AL-fleece
Copper strands (audio): 128
Copper strand Ø (audio): 0,05 mm
Conductor insulation material: PE
Conductor insulation Ø: 1,55 mm
Weight per 1 m: 48 g
UV-resistant: yes
Fire load per m: 0,21 kWh
Style variant: round
Shielding factor: 100 %
Packing: 500 m spool
Packing: 100 m spool
Temperature min.: -25 °C
Temperature max.: 70 °C
Width: 6,5 mm
Height: 6,5 mm
Capac. cond./cond. per 1 m (audio): 60 pF
Capac. cond./shield. per 1 m (audio): 110 pF
Insulation resist. per 1 km: 0,2 GΩ
Insulation resist. per 1 km (audio): 0,2 GΩ
Conductor resistance per 1 km: 78 Ω
Shield. resistance per 1 km: 25 Ω
